SLA MACHINE Features:
• Two-layer workstation design with a high-precision granite base structure that ensures exceptional stability and rigidity, with no deformation of the mechanism.
• Precision-grade V-shaped cross-roller guides combined with a toothless screw ensure high mechanical accuracy.
• High-quality optical system and high-resolution CCD ensure high-quality measurement images.
• Lenses are coated with multi-layer coatings and designed for stepless zoom, providing convenience for fixed usage without integer magnification slots.
• LED ring surface cold light source and contour cold light source to prevent heat generation during work, which can cause deformation.
• Professional vision measurement software with powerful features, easy operation, and stable, high-precision optical non-contact measurement of height and depth.
| Model | SLA2010 | SLA3020 | SLA4030 | SLA5040 | |
| Measurement Range(mm)* | 200×100×150 | 300×200×150 | 400×300×200 | 500×400×200 | |
| Overall Size | 540×760×1750 | 640×860×1750 | 780×1000×1750 | 880×1220×1750 | |
| Weight(kg) | 200 | 280 | 480 | 600 | |
| Load Bearing(kg) | 25 | 25 | 25 | 25 | |
| Measurement Accuracy(μm) (L for Length:mm） | E2(X/Y)=(3.0+L/200) | E2(X/Y)=(3.0+L/200) | E2(X/Y)=(3.5+L/200) | E2(X/Y)=(3.5+L/200) | |
| Linear Encoder | 1.0μm linear encoder (Optional: 0.5μm linear encoder) | ||||
| Rail | Cross roller rail/roller linear rail | ||||
| Image Sensor | HD color industrial camera | ||||
| Illuminant ** | Profile | LED White light (Green filter can be added) | |||
| Surface | LED Ring light (Optional: Green/ Red/ Coaxial light) | ||||
| Optical Lens | Freeze-frame multi-segment magnification telecentric lens (Optional: motorized zoom lens) | ||||
| Magnification*** | Optical magnification：0.7~4.5X；Image magnification：22~144X | ||||
| Software | VMM Measurement software(Manual version) | ||||
| Operation | X&Y axis | Hand wheel+ Fast movement | |||
| Z axis | Hand wheel/ Electric movement | ||||
| Working Conditions | Temperature 20℃±3℃，Temperature Change＜2℃/h，Humidity 30~80% | ||||
| Vibration＜0.002g，less than 15Hz | |||||
| Power Source | 220-240V，50-60Hz，Single phase，200W | ||||
| Optional Models | Customization：600×500mm，700×600mm OMM (Manual) | ||||
* Z-axis can be increased to 350mm.
** Coaxial light is optional, and the technical parameters are the same as contour light.
***Magnification is approximate value (It’s related to the size and the resolution of the computer display). Customers can choose 0.5X / 2X lens (if required) to achieve image magnification of 11~110X /40~280X.
